MD12

A 32A three-phase (400V) event power distribution box designed to distribute temporary power from one area to another. The 32A plug and play distribution board is easy to relocate across site and blends in well with the surrounding environment.

Technical Information

All switchgear and Tri-rated wiring is housed within an insulated thermoplastic enclosure, with recessed socket and switchgear panels for mechanical protection. Transparent windows are used to allow visual identification of the switchgear status and allow access in event of a trip. The enclosure incorporates integrated carry handles, stacking feet/raisers, external brass earth stud and all necessary electrical hazard warning identification.

The enclosure material is black 4mm LLDPE, a robust and shock resistant thermoplastic, complete with foam rubber sealing material (EPDM). IK10 rated.

Specification:

  • Incomer: 32A 400V 3P+N+E IP44 Appliance Inlet. Protection: 32A 4P MCB
  • Outgoing: 9 x 16A 230V 1P+N+E IP44 Pnl Mnt Skt. Protection: 9 x 16A 2 Pole 30mA RCBO
  • Outgoing: 1 x 32A 400V 3P+N+E IP67 Pnl Mnt Skt. Protection: No
  • Dimensions H340 x W400 x D350 (mm)
  • Weight: 12kgs

All temporary power distribution equipment is manufactured by IDE  in the UK and tested to BS 7671 (12 Months Certification). The products used within our distribution systems conform to EN 60309, EN 60529, EN 60947 and have a 12 month warranty.
