MD403
The MD403 is one of our most versatile & utilised 400a board. This board is the stalwart of any event or festival, providing no less than 15 outgoing ways of various amperage & both three- & single-phase options. For added protection it is HPDE board is protected with a 25mm box section stainless steel (316L) crash frame complete with forklift pockets.
Technical Information
Inlet: 400APowerlocks, 3+N 400A MCCB N/A 67
Outgoing:
3 x 16A 230v 30mA RCBO
3 x 32A 230v 30mA RCBO
6 x 32A 3+N 30mA RCBO
3 x 63A 3+N MCB+30mA RCD
3 x 125A 3+N MCCB + Adjustable ELR
1 x 400A 3+N Powerlock Feedthrough (Drain)
Size (mm): H1392 x W612 x D495
Weight (kg): 110Kg
IP44
