MD11
A 32A three-phase (400V) rubber box distribution board designed to distribute temporary power from one area to another. The 32A plug and play distribution board is easy to relocate across site and blends in well with the surrounding environment.
Technical Information
All switchgear and Tri-rated wiring is housed within a solid cast rubber enclosure. An integrated transparent window is used to allow visual identification of the switchgear status and allow access in event of a trip. Incoming 32A supply plug sits on a 6mm 5 core H07RN-F flying lead to allow ease of connection to a socket outlet. The enclosure incorporates a carry handle, stacking feet/raisers and all necessary electrical hazard warning identification.
The enclosure is a black, self extinguishing, fully insulated, stackable, hard butyl rubber spider, with high resistance to chemical agents, atmospherics and current leakage. IK10 rated. IP55 rated.
Specification:
- Incomer: 32A 400V 3P+N+E IP44 Plug on 1m Lead. Protection: No
- Outgoing: 3 x 32A 230V 1P+N+E IP44 Pnl Mnt Skt. Protection: 3 x 32A 2 Pole 30mA RCBO
- Dimensions: H300 x W400 x D350 (mm)
- Weight: 10kg
All temporary power distribution equipment is manufactured by IDE in the UK and tested to BS 7671 (12 Months Certification) and the products used within our distribution systems conform to EN 60309, EN 60529, EN 60947 and have a 12 month warranty.
