MD32

A 125A three-phase (400V) power distro box designed to distribute temporary power from one area to another. The 125A distro is plug and play which means that it is easy to relocate across site and blends in well with the surrounding environment.

Technical Information

All switchgear and Tri-rated wiring is housed within a purpose built high density polyethylene enclosure, with recessed socket and switchgear panels for mechanical protection. Transparent windows are used to allow visual identification of the switchgear status and allow access in event of a trip. The enclosure incorporates integrated carry handles, common stacking rails, external brass earth stud and all necessary electrical hazard warning identification.

The enclosure is fabricated from black 10mm thick 300-grade high density polyethylene, offering good impact resistance, chemical resistance and high rigidity. Density of 0.96 g/cm³, less than 0.01% moisture absorption, service temperature from -50 to +80°C with greater than 1014 surface resistance. IK09 Rated.

Specification:

  • Incomer: 125A 400V 3P+N+E IP67 Appliance Inlet. Protection: 125A 4 Pole MCCB
  • Outgoing: 1 x 63A 400V 3P+N+E IP44 Pnl Mnt Skt. Protection: 63A 4 Pole C-Type MCB
  • Outgoing: 2 x 32A 400V 3P+N+E IP44 Pnl Mnt Skt. Protection: 2 x 32A 4 Pole 30mA RCBO
  • Outgoing:12 x 32A 230V 1P+N+E IP44 Pnl Mnt Skt. Protection: 12 x 32A 2 Pole 30mA RCBO
  • Outgoing: 6 x 16A 230V 1P+N+E IP44 Pnl Mnt Skt. Protection: 6 x 16A 2 Pole 30mA RCBO
  • Dimensions: H600 x W550 x D495 (mm)
  • Weight: 41kg

All temporary power distribution equipment is manufactured by IDE in the UK and tested to BS 7671 (12 Months Certification). The products used within our distribution systems conform to EN 60309, EN 60529, EN 60947 and have a 12 month warranty. All IDE temporary power distros are built with Mennekes sockets and ABB switchgear as standard.
