MD6

A 63A three-phase (400V) rubber box distribution board designed to distribute temporary power from one area to another. The 63A plug and play distribution board is easy to relocate across site and blends in with the surrounding environment.

Technical Information

All switchgear and Tri-rated wiring is housed within a solid cast rubber enclosure. An integrated transparent window is used to allow visual identification of the switchgear status and allow access in event of a trip. Incoming 63A supply plug sits on a 16mm 5 core 1 metre H07RN-F flying lead to allow ease of connection to a socket outlet.

The enclosure is a black, self extinguishing, fully insulated, stackable, hard butyl rubber spider, with high resistance to chemical agents, atmospherics and current leakage. IK10 rated.

Specification:

63A 3PH HDPE Event Distribution

Incomer: 63A/3 5core 1 m Flying lead

Outgoing: unprotected feed thru - 2 x 32/3 sockets IP44 - 4P MCB

Dimensions:  W354 x H254 x D250

Weight: 17kg

Rating: IP44

All temporary power distribution boxes are manufactured by IDE in the UK and tested to BS 7671 (12 Months Certification) and the products used within our distribution systems conform to EN 60309, EN 60529, EN 60947 and have a 12 month warranty.
